Eagle Cage Netting

This tab include the details of:

1. Zoo Mesh Installation

2. Mesh Panels Connection

3. Fitting and Tools

4. Other notes ( About Special Shape installation )

1. Install the stainless steel wire rope zoomesh for zoo eagle netting

▼ Specific installation methods of wire rope netting mesh

 → PIC A1: Preparation work

 1. the bags of wire rope woven mesh you received

 2. open the bags you will see the mesh rolled

 3. expand the zoo mesh, the natural mesh each angles are not 90°

 4. some of these fittings: wire ropes, ferrules, tongs, ect

 Then, install according to the following methods.

 The diagram of standard installing method of stainless steel rope woven mesh.

 → PIC A2, A3, A4: Install steps

 Step 1, Determine the width and height of mesh direction according the pic A2;

 Step 2, First fix the two corners with cable ties, said, first fix 1 and 1 mark at;

 Step 3, Fix TOP line A;

 Step 4, Fix height direction's 2 and 2, 3 and 3, 4 and 4,5 and 5... codes at the left and right followed by uniform in pic A3

 Step 5, Fix the mesh to the bottom;

 Step 6, Using the wire ropes back and forth between the mesh and frame, this method is the most common way, fast and strong.

 Step 7, The ends of both perimeter ropes must be threaded through a ferrule and then pulled taught. Now, all the cable ties can be remove.

 Step 8. Swage the ferrule with the swaging tool, and cut off lose ends of the perimeter rope. Now, each of the mesh angle is 90 °.

Animal netting mesh install details -1:

Have the wire rope back and forth between the mesh and frame, this method the most common way, fast and strong.

△ Installation details of edges of wire rope netting mesh

Animal netting mesh install details -2

△ Ferrules with eye installation details of the wire rope mesh edge

2. Join the two panels of wire rope netting mesh (Vertical and horizontal)

For the convenience of the production, transportation and installation, we usually produce the wire rope mesh panel in size of 10m X 20m, if you are about to oder the over size mesh panel, you may extend or increas the mesh to your size by the following way,
▽(1) to increase the length of the wire rope mesh: use the wire ropes to connect the two edges of the two mesh, like stitching.



(2) there are two way in which you could increase the vertical height of the wire rope netting mesh:
▽A. use the wire rope to connect the two edges of the two mesh, like stitching.





This tab include the details of:

1. Free Samples

2. Packing zoo mesh

3. Shipping zoo mesh

4. Order Process

2) Let us have your Freight Collect Account No. you registered in the above couriers; we will arrange the shipment by contacting their local branches.

2. Packing the wire rope eagle netting zoo mesh

Mesh Panel Standard size is 35ft x 70ft ( 10.6m x 21.3m )

Mesh can be produced as customers' required sizes, but each panel is better not large than 10.6m x 21.3m, for convenient to production, shipping and installation.

The Size of " Bulk Roll " :

Usually, the size of bulk roll is approx. 700mm X 700mm X 600mm per 100kg, in the cubic shape, the measurement is approx. 0.3M3. It may vary due to the size of mesh you ordered.

3. Shipping the zoo wire rope netting mesh

A variety of transportation ways for your choose.

★ Notes:

The company of express you can choose like: FedEx, DHL, TNT, or UPS.

We also accept the freight collect.

Our nearest sea port: XINGANG PORT, TIANJIN, CHINA

Our nearest air port: BEIJING, CHINA

△Packing and Shipping the stainless steel wire netting mesh
