Tiger Enclosure Mesh

This tab include the details of:

1. Zoo Mesh Installation

2. Mesh Panels Connection

3. Fitting and Tools

4. Other notes ( About Special Shape installation )

1. Install the stainless steel wire rope zoomesh for zoo tiger netting

▼ Specific installation methods of wire rope netting mesh

 → PIC A1: Preparation work

 1. the bags of wire rope woven mesh you received

 2. open the bags you will see the mesh rolled

 3. expand the zoo mesh, the natural mesh each angles are not 90°

 4. some of these fittings: wire ropes, ferrules, tongs, ect

 Then, install according to the following methods.

 The diagram of standard installing method of stainless steel rope woven mesh.

 → PIC A2, A3, A4: Install steps

 Step 1, Determine the width and height of mesh direction according the pic A2;

 Step 2, First fix the two corners with cable ties, said, first fix 1 and 1 mark at;

 Step 3, Fix TOP line A;

 Step 4, Fix height direction's 2 and 2, 3 and 3, 4 and 4,5 and 5... codes at the left and right followed by uniform in pic A3

 Step 5, Fix the mesh to the bottom;

 Step 6, Using the wire ropes back and forth between the mesh and frame, this method is the most common way, fast and strong.

 Step 7, The ends of both perimeter ropes must be threaded through a ferrule and then pulled taught. Now, all the cable ties can be remove.

 Step 8. Swage the ferrule with the swaging tool, and cut off lose ends of the perimeter rope. Now, each of the mesh angle is 90 °.

Animal netting mesh install details -1:

Have the wire ropes back and forth between the zoo mesh and frame, this method the most common way, fast and strong.

△ Installation details of edges of wire rope netting mesh

Animal netting mesh install details -2:

Using the ferrules with "eyes", in this way, we need to reserve the ferrules with "eyes" on the four edges during the production. The specific method is also to use wire rope go through the ferrules, and make it back and forth between the frame and the ferrules with "eyes". The benefits of doing so so very beautiful, and always adopted on the decoration. If you have interests, please specify when ordering.

△ Ferrules with eye installation details of the wire rope mesh edge

▽(1) to increase the length of the wire rope mesh: use the wire ropes to connect the two edges of the two mesh, like stitching.
